BLUE SMART IP22 CHARGER 24/16 (3) AU/NZ

(1 customer review)

$394.39

Victron Energy Blue Smart IP22 Charger 24/16 (3) AU/NZ

24V, 16A, 3 outputs. Built-in Bluetooth, AU/NZ ac-plug.

Fully automatic battery charger with wireless solution to monitor voltage and current, to change settings, and to update the charger via smartphone.

FREE URBAN SHIPPING on all batteries under 25kg .

For delivery outside of main centres, please contact us for a quote.

SKU: V-BS24/16(3) Category:

BLUE SMART IP22 CHARGER 24/16:

Bluetooth Smart enabled - The Blue Smart IP22 Charger is the wireless solution to monitor voltage and current, to change settings, and to update the charger when new features become available. The highest efficiency ever! With up to 94% efficiency, these chargers generate up to four times less heat when compared to the industry standard. And once the battery is fully charged, power consumption reduces to 0,5 Watt, some five to ten times better than the industry standard. NIGHT and LOW setting - When in NIGHT or LOW mode, the output current is reduced to max. 25% of the nominal output and the charger will be noiseless. The NIGHT mode automatically ends after 8 hours. The LOW mode can be ended manually.

Victron Blue Smart Bluetooth 24-volt 16-amp three output battery charger with IP22 rating suitable for AGM, Gel and Lithium Ion battery charging.



ModelBPC241644012
Output Current Rating (Amps)16.0 Amps
Efficiency94%
Operating Temperature Range-20 to +50°C
HumidityMax 98%
Output3
Output System Voltage24V
Charge current16 A
Dimensions108 x 65 x 235 mm (L x W x H)
Net Weight (kg)1.3 Kg
Charge Algorithm6-stage adaptive
Charge voltage 'absorption'Normal: 28.8V | High: 29.4V | Li-ion: 28.4V
Charge Voltage Float - Wet (25 degrees)**Normal: 27.6V | High: 27.6V | Li-ion: 27.0V
Charge voltage 'storage'Normal: 26.4V | High: 26.4V | Li-ion: 27.0V
ProtectionBattery reverse polarity (fuse), Output short circuit, and Over temperature
Charge current in low current mode8 A
No load power consumption0.5 W
Protection categoryIP22
Battery-connectionScrew terminals 13 mm² / AWG6
Input Voltage180 – 265 VAC
Can be used as power supplyYes
Manufacturers Warranty5 Years
